What do I know? Skills — industrial automation, PLC & HMI
Enough to know where it runs out. I work along the whole line, from the sensor and the PLC to the HMI and the report on the office share, and I'm honest about the levels.
Bibin V R uses these skills on real machines, from Siemens and Mitsubishi PLCs to EPLAN schematics and Raspberry Pi edge controllers. Each one has a level and a note.
Featured · PLC & motion · level 82
Siemens TIA Portal
TIA Portal V17 and V21 with S7-1200, S7-1200 G2 and S7-1500 CPUs: hardware, tag tables, blocks, compile and download. A ladder conveyor program built through TIA-Portal-MCP runs on a real S7-1200 G2.
- Siemens TIA Portal — PLC & motion · 82. TIA Portal V17 and V21 with S7-1200, S7-1200 G2 and S7-1500 CPUs: hardware, tag tables, blocks, compile and download. A ladder conveyor program built through TIA-Portal-MCP runs on a real S7-1200 G2.
- Mitsubishi GX Works3 — PLC & motion · 82. GX Works3 projects in Ladder, Structured Text, FBD and SFC. GXBridge builds and downloads them, runs and stops the PLC, and reads, writes and monitors live device values.
- IEC 61131-3 languages — PLC & motion · 80. LAD and SCL blocks in TIA Portal, with FBD, STL and GRAPH by import. Ladder, Structured Text, FBD and SFC in GX Works3, with PLCopen XML export and import.
- Commissioning & simulation — PLC & motion · 78. Commissioning in S7-PLCSIM before a real PLC: load, RUN and STOP, online compare, and reload after a change. On the machine, PiCW has guarded output forcing and a learn mode for the reject delay.
- Motion control — PLC & motion · 68. Positioning axes, drive telegrams and isochronous servo mode in TIA Portal, built for a 6-axis pick-and-place cell on a CPU 1511T with six SINAMICS S210 drives on PROFINET IRT. The EPLAN robot-arm schematic draws six MR-J4-B servo axes on two FX5-40SSC-S modules.
- SLMP (MC protocol) — HMI & networks · 82. Tovex-ARM reads every item off a Mitsubishi PLC over SLMP, the MC protocol. It runs in production on the check-weigher and VTD lines at Sai Samarth Engineering in Goa.
- Modbus RTU — HMI & networks · 80. PiCW reads a Thames Side XT1-SO weighing transmitter over RS485 Modbus RTU, 24-bit at 2400 readings a second, and reconnects with backoff.
- Shop-floor HMIs — HMI & networks · 80. Touchscreen HMIs and line displays on Raspberry Pi: PiCW's HMI and setup wizard, and the CW-2400 check-weigher dashboard on a 7-inch touchscreen at Sai Samarth Engineering.
- S7 communication — HMI & networks · 76. The S7 client inside tovex-cli reads and writes inputs, outputs, memory and data blocks on a real S7-1200 G2, and returns the same bytes as python-snap7.
- WinCC HMI — HMI & networks · 70. WinCC Unified and Comfort/Advanced panels built through TIA Portal Openness: PLC connections, tags, screens, buttons, I/O fields and their events.
- PROFINET — HMI & networks · 70. PROFINET networks in TIA Portal: device IP addresses, topology, and IRT for isochronous servo axes.
- Load cells & sensors — Electrical & field · 80. Thames Side T16 load cells and XT1000 transmitters over Modbus RTU, with photo-eyes at the entry and exit, for in-motion check-weighing.
- Safety interlocks — Electrical & field · 72. On PiCW the E-stop and guard interlocks are hardwired through a safety relay, and no part of the software is a safety function. The robot-arm schematic carries STO, and the TIA conveyor program latches its E-stop until a reset.
- EPLAN Pro Panel — Electrical & field · 70. A 20-page schematic for a 6-axis robot arm on an FX5U PLC, built through the EPLAN API from outside the GUI, with 273 symbols and 129 connections placed by script. It covers the supply, 24 V DC, safety and STO, and draws the cabinet on a mounting plate at 1:7.
- Raspberry Pi — Edge & IIoT · 90. Industrial edge deployments that run unattended around the clock: PLC data loggers, check-weigher controllers and shop-floor kiosks.
- Real-time Linux — Edge & IIoT · 85. Tovex-ARM runs on a PREEMPT_RT kernel, with the collector at real-time priority on its own isolated CPU core. Its services are self-healing, and system upgrades pin the real-time kernel, so an update can't break a running line.
- Data logging & reports — Edge & IIoT · 82. Tovex-ARM turns PLC data into a batch PDF report and puts it on the office share over SMB, with store-and-forward delivery and recovery after a power cut. PiCW keeps products, items, events and an audit log in SQLite (WAL).
- Plant networks & SMB — Edge & IIoT · 75. The Pi reaches the PLC on a dead-end subnet with its own static IP, so that network can never take over the machine's default route. Reports go to Windows shares over SMB.
- Python — Software & AI · 92. Primary language for industrial IoT: PLC data loggers, real-time register polling, FastAPI services and AI tooling.
- AI agents & MCP — Software & AI · 82. MCP servers that let Claude or any AI agent work a PLC: GXBridge, with 46 tools for GX Works3, and TIA-Portal-MCP for TIA Portal. Both wait for your confirmation before a download to the PLC.
- TIA Portal Openness — Software & AI · 78. tovex-cli and TIA-Portal-MCP both drive TIA Portal V17 and V21 through Openness: projects, blocks, tag tables and HMI objects from code, then compile and download.
- C# / .NET — Software & AI · 64. The eplanbridge core calls the EPLAN API in typed C# on .NET Framework 4.8, and tovex-cli compiles a small C# helper on the engineering PC that drives TIA Portal through Openness.
How do I decide?
What does the machine demand?
I design software that respects the physical world — timing, noise, flaky networks, and 24/7 uptime on constrained devices.
Where does my part end?
From a sensor reading to a deployed dashboard, I'm comfortable owning the full path rather than a single layer.
What is a system for?
I optimize for systems that keep running in production, not demos. Reliability and clarity over cleverness.
